Machine Type: Trapezoidal Roll Forming Machine
Material: Galvanized steel, PPGI, Aluminum
Material Thickness: 0.3 - 0.8 mm
Forming Speed: 12-18 m/min
Roller Stations: 16-20 rows
Roller Material: 45# steel with hard chrome
Shaft Diameter: 75 mm
Drive Type: Chain or gear drive
Cutting System: Hydraulic cutting with Cr12 steel blade
PLC System: Siemens/Delta with touch screen
Main Motor Power: 5.5 kW
Hydraulic Power: 4.0 kW
Power Supply: 380V/50Hz/3Phase
Feeding Width: 1000 mm
Effective Width: 828 mm
Panel Shape: Trapezoidal
Frame: 300H steel welded structure
Cutting Accuracy: ±1 mm
Machine Color: Blue & customizable
Dimensions: 8500 x 1500 x 1500 mm
Weight: Approx. 6.5 tons
Packing: Plastic film + steel pallet
Delivery Time: 30 days
Certification: CE & ISO9001
Warranty: 1 year
Support: Online and overseas
Noise Level: Low
Daily Capacity: 8 hours/day
Application: Roofing, siding, cladding
Automation: Full PLC control
Safety: Emergency stop and circuit protection
This high-speed roll forming machine is designed for industrial-grade performance in the continuous production of trapezoidal metal roofing panels. Its strong steel frame, advanced control system, and precise hydraulic cutting offer long-lasting and stable operation under heavy workloads.
